| Image Sensor |
1/2.7” Progressive Scan CMOS
|
| Signal System |
PAL/NTSC
|
| Min. Illumination |
Color: 0.01 Lux @ (F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR
|
| Shutter time |
1/3 s to 1/100,000 s
|
| Slow shutter |
Support
|
| Lens |
2.8 mm: Horizontal field of view: 114°, Vertical field of view: 62°, Diagonal field of view: 135° 4 mm: Horizontal field of view: 86°, Vertical field of view: 46°, Diagonal field of view: 102° 6 mm: Horizontal field of view: 54°, Vertical field of view: 30°, Diagonal field of view: 62°
|
| Lens Mount |
M12
|
| Adjustment Range |
Pan: -30° to +30°, tilt: 0° to 75°, rotate: 0° to 360°
|
| Day& Night |
IR Cut Filter
|
| Wide Dynamic Range |
120 dB
|
| Digital noise reduction |
3D DNR
|
| Focus |
Fixed
|
| Video Compression |
H.265+/H.265/H.264+/H.264/MJPEG
|
| H.264 code profile |
Main Profile/High Profile
|
| Video bit rate |
256Kbps~16Mbps
|
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM
|
| Audio bit rate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
|
| Triple Streams |
Yes
|
| Max. Image Resolution |
1920 x 1080
|
| Frame Rate |
50Hz:25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
|
| Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
|
| Third Stream |
50Hz: 25fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 240)
|
| Image Enhancement |
BLC/3D DNR/ROI/HLC
|
| Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
|
| ROI |
Support 1 fixed region for main stream and sub-stream separately
|
| Day/Night Switch |
Auto/Schedule/Day/Night/Triggered by Alarm In (-S)
|
| Network Storage |
microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
|
| Alarm Trigger |
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
|
| General Function |
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering
|
| System Compatibility |
ONVIF (Profile S, Profile G), ISAPI
|
| Audio |
with -S model：2 Inputs: line in or mic in (built-in microphone), 1 output: line out, mono sound, terminal block
|
| Communication Interface |
1 RJ45 10M / 100M Ethernet interface
|
| Alarm |
1 Input: Alarm in, 1 Output: Alarm out (max. 12 VDC, 30 mA), terminal block
|
| On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
|
| Reset Button |
Yes
|
| Environment Noise Filtering |
Support
|
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz
|
| Behavior Analysis |
Line crossing detection, intrusion detection
|
| Line Crossing Detection |
Cross a pre-defined virtual line
|
| Intrusion Detection |
Enter and loiter in a pre-defined virtual region
|
| Recognition |
Face Detection
|
| Wireless Standards |
IEEE802.11b, 802.11g, 802.11n
|
| Frequency Range |
2.412 GHz to 2.4835 GHz
|
| Channel Bandwidth |
20/40MHz Support
|
| Security |
WPA, WPA2
|
| Transmission Rate |
11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps
|
| Wireless Range |
50m(depend on environment)
|
| Protocols |
802.11b: DQPSK, DBPSK, CCK 802.11g/n: OFDM /64-QAM,16-QAM, QPSK, BPSK
|
| Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
|
| Power Supply |
12 VDC ± 25%, PoE (802.3af Class3)
|
| Power Consumption |
12 VDC, 0.7 A, max. 8.5W, Φ 5.5mm coaxial plug power PoE (802.3af, 36V to 57V), 0.3 A to 0.1 A, max. 10W
|
| Impact Protection |
IK08 Protection Level
|
| Weather Proof |
IP66
|
| IR Range |
Up to 10m
|
| Dimensions |
Φ110 mm × 56.4 mm (Φ4.3" × 2.2")
|
| Weight |
Camera: Approx. 400 g (0.9 lb.)
|
