| Image Sensor |
1/2.7" Progressive Scan CMOS
|
| Min. Illumination |
Color: 0.01 Lux @ (F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR
|
| Shutter Speed |
1/3 s to 1/100,000 s
|
| Slow Shutter |
Yes
|
| Day & Night |
IR Cut Filter
|
| Digital Noise Reduction |
3D DNR
|
| WDR |
120dB
|
| 3-Axis Adjustment |
Pan: -30°to +30°, tilt: 0°to 75°, rotate: 0°to 360°
|
| Focal length |
2.8, 4, 6 mm
|
| Aperture |
F2.0
|
| FOV |
2.8 mm: Horizontal field of view: 114°, Vertical field of view: 62°, Diagonal field of view: 135° 4 mm: Horizontal field of view: 86°, Vertical field of view: 46°, Diagonal field of view: 102° 6 mm: Horizontal field of view: 54°, Vertical field of view: 30°, Diagonal field of view: 62°
|
| Lens Mount |
M12
|
| IR Range |
Up to 10 m
|
| Wavelength |
850nm
|
| Video Compression |
Main stream: H.265/H.264 Sub stream: H.265/H.264 /MJPEG Third stream: H.265/H.264
|
| H.264 Type |
Main Profile/High Profile
|
| H.264+ |
Yes
|
| H.265 Type |
Main Profile
|
| H.265+ |
Yes
|
| Video Bit Rate |
32 Kbps to 16 Mbps
|
| Audio Compression |
G722.1/G711ulaw/G711alaw/G726/MP2L2/PCM
|
| Audio Bit Rate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
|
| Behavior Analysis |
Line crossing detection, intrusion detection
|
| Face Detection |
Yes
|
| Region of Interest |
Support 1 fixed region for main stream and sub-stream separately
|
| Max. Resolution |
1920 × 1080
|
| Main Stream |
50Hz:25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
|
| Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
|
| Third Stream |
Third Stream 50Hz: 25fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 240)
|
| Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser
|
| Image Enhancement |
BLC/3D DNR
|
| Day/Night Switch |
Auto/Schedule/Day/Night/Triggered by Alarm In (-S model)
|
| Network Storage |
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
|
| Alarm Trigger |
Motion detection, video tampering, network disconnected, IP address conflict, HDD full, HDD error, illegal login
|
| General Function |
One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
|
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI
|
| Simultaneous Live View |
Up to 6 channels
|
| User/Host |
Up to 32 users 3 levels: Administrator, Operator and User
|
| Client |
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
|
| Web Browser |
IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
|
| Audio |
2 Inputs: line in (3.5 mm) or mic in (built-in microphone), 1 Output: line out (3.5 mm), mono sound
|
| Alarm |
1 Input: Alarm in (3.5mm) 1 Output: Alarm out (3.5mm)
|
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port
|
| On-board storage |
Built-in MicroSD/SDHC/SDXC slot, up to 128G
|
| SVC |
Support H.264 and H.265 encoding
|
| Wireless Standards |
IEEE 802.11b/g/n
|
| Frequency Range |
2.412 GHz to 2.4835 GHz
|
| Channel Bandwidth |
20M/40M
|
| Protocols |
802.11b: DQPSK, DBPSK, CCK 802.11g/n: OFDM /64-QAM,16-QAM, QPSK, BPSK
|
| Security |
WPA, WPA2
|
| Transfer Rates |
11b: 11Mbps, 11g: 54Mbps, 11n: up to 150Mbps
|
| Wireless Range |
50 m
|
| Environment Noise Filtering |
Yes
|
| Audio Sampling Rate |
16 kHz, 32kHz, 44.1kHz, 48kHz
|
| Operating Conditions |
-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
|
| Power Supply |
12 VDC ± 25%, PoE (802.3af, class 3)
|
| Power Consumption and Current |
12 VDC, 0.7 A, max. 8.5W, Φ 5.5mm coaxial plug power PoE (802.3af, 36V to 57V), 0.3 A to 0.1 A, max. 10W
|
| Protection Level |
IK08, IP66
|
| Material |
Front cover: plastic, Bottom base: metal
|
| Dimensions |
Φ110 mm × 56.4 mm (Φ4.3" × 2.2")
|
| Weight |
Camera: Approx. 400 g (0.9 lb.)
|
