| Image Sensor |
1/3" Progressive Scan CMOS
|
| Signal System |
PAL/NTSC
|
| Min. Illumination |
Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
|
| Shutter time |
1/3 s to 1/100,000 s
|
| Slow shutter |
Support
|
| Lens |
2.8 mm @ F1.6: horizontal FOV: 103°, vertical FOV: 58°, diagonal FOV: 123° 4 mm @F1.6: horizontal FOV: 83°, vertical FOV: 45°, diagonal FOV: 99° 6 mm @F1.6: horizontal FOV: 51°, vertical FOV: 29°, diagonal FOV: 58° 8 mm @F1.6: horizontal FOV: 39°, vertical FOV: 22°, diagonal FOV: 45°
|
| Lens Mount |
M12
|
| Adjustment Range |
Pan: 0° to 360°, tilt: 0° to 100°, rotate: 0° to 360°
|
| Day& Night |
IR cut filter with auto switch
|
| Wide Dynamic Range |
120 dB
|
| Digital noise reduction |
3D DNR
|
| Focus |
Fixed
|
| Video Compression |
H.265+/H.265/H.264+/H.264/MJPEG
|
| Video bit rate |
256Kbps~16Mbps
|
| Triple Streams |
Yes
|
| Max. Image Resolution |
2688 × 1520
|
| Frame Rate |
50Hz:25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080) 60Hz: 30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080)
|
| Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
|
| Third Stream |
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)
|
| Image Enhancement |
BLC/3D DNR/BLC
|
| Image Settings |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
|
| Target Cropping |
No
|
| ROI |
1 fixed region for main stream and sub-stream
|
| Day/Night Switch |
Day/Night/Auto/Schedule
|
| Network Storage |
Support micro SD/SDHC/SDXC card (128G), flash memory , ANR
|
| Alarm Trigger |
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
|
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP?, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
|
| General Function |
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering
|
| System Compatibility |
ONVIF (Profile S, Profile G),ISAPI
|
| Communication Interface |
1 RJ45 10M / 100M Ethernet interface
|
| On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
|
| Behavior Analysis |
Line crossing detection, intrusion detection
|
| Line Crossing Detection |
Cross a pre-defined virtual line
|
| Intrusion Detection |
Enter and loiter in a pre-defined virtual region
|
| Recognition |
Face Detection
|
| Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
|
| Power Supply |
12 VDC ± 25%, PoE (802.3af Class3)
|
| Power Consumption |
-I5:12 VDC, 0.6A, max. 7.5W PoE (802.3af, 37V to 57V), 0.2A to 0.1A, max. 9.5W -I8:12 VDC, 0.95A, max. 11.5W PoE (802.3af, 37V to 57V), 0.35A to 0.1A, max. 12.5W
|
| Weather Proof |
IP67
|
| IR Range |
up to 80 m
|
| Dimensions |
Camera: Φ 105 × 299.7 mm (Φ 4.1" × 11.8") Package: 386 × 156 × 155 mm (15.2" × 6.14" × 6.1")
|
| Weight |
Camera: Approx. 1180 g (2.6 lb.) With Package: Approx. 1700 g (3.7 lb.)
|
