| Image Sensor |
1/2.8″ Progressive Scan CMOS
|
| Min. Illumination |
Color: 0.01 Lux @ (F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR
|
| Shutter Speed |
1/3 s to 1/100,000 s
|
| Slow Shutter |
Yes
|
| Auto-Iris |
No
|
| Day & Night |
IR Cut Filter
|
| Digital Noise Reduction |
3D DNR
|
| WDR |
DWDR
|
| 3-Axis Adjustment |
Pan: 0° to 360°, tilt: 0° to 100°, rotate: 0° to 360°
|
| Focal length |
2.8/4/6 mm
|
| Aperture |
F2.0
|
| Focus |
Manual
|
| FOV |
4 mm: horizontal FOV: 86°, vertical FOV: 46°, diagonal FOV: 102° 6 mm: horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 62°
|
| Lens Mount |
M12
|
| IR Range |
30 m
|
| Wavelength |
850nm
|
| Video Compression |
Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG
|
| H.264 Type |
Main Profile/High Profile
|
| H.264+ |
Main stream and sub-stream support
|
| H.265 Type |
Main Profile
|
| H.265+ |
Main stream and sub-stream support
|
| Video Bit Rate |
32 Kbps to 16 Mbps
|
| Behavior Analysis |
Line crossing detection, intrusion detection
|
| Region of Interest |
1 fixed region for main stream and sub-stream
|
| Max. Resolution |
1920 × 1080
|
| Main Stream |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
|
| Sub-Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
|
| Image Enhancement |
BLC/3D DNR
|
| Image Setting |
Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser
|
| Target Cropping |
No
|
| Day/Night Switch |
Auto/Schedule
|
| Network Storage |
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
|
| Alarm Trigger |
Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error
|
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
|
| General Function |
One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
|
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI
|
| Simultaneous Live View |
Up to 6 channels
|
| User/Host |
Up to 32 users 3 levels: Administrator, Operator and User
|
| Client |
iVMS-4200, Hik-Connect, iVMS-5200
|
| Web Browser |
IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
|
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port
|
| Video Output |
No
|
| On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
|
| Operating Conditions |
-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
|
| Power Supply |
12 VDC ± 25%, Φ 5.5 mm coaxial power plug PoE (802.3af, class 3)
|
| Power Consumption and Current |
12 VDC, 0.6A, max. 5.5W PoE (802.3af, 37V to 57V), 0.2A to 0.1A, max. 8W
|
| Protection Level |
IP67 TVS 2000V Lightning Protection, Surge Protection and Voltage Transient Protection
|
| Material |
Metal & Plastic
|
| Dimensions |
Camera: 93.85 × 89.52 × 194.04 mm
|
| Weight |
Camera: Approx. 750g
|
