| Image Sensor: |
1/2.8" HD progressive scan CMOS
|
| Effective Pixels: |
1920(H)x1080(V)
|
| Signal System: |
PAL/NTSC
|
| Minimum Illumination: |
Color: 0.005 Lux @(F1.6, AGC ON) B/W: 0.001Lux @(F1.6, AGC ON) 0 Lux with IR
|
| White Balance: |
Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
|
| BLC: |
ON/OFF
|
| HLC: |
Support
|
| Smart defog: |
Support
|
| WDR: |
120dB
|
| Shutter Time: |
1-1/10,000s
|
| Day& Night: |
ICR
|
| Digital Zoom: |
16X
|
| Privacy Mask: |
24 programmable privacy masks; optional multiple colors and mosaics
|
| Auto Focus: |
Auto / Semi-automatic / Manual
|
| Focal Length: |
4.8 mm to 153 mm, 32× optical zoom
|
| Zoom Speed: |
Approx. 5.6 s (optical lens, wide-tele)
|
| Field of View: |
Horizontal field of view: 55.6° to 2.04° (Wide-Tele) Vertical field of view: 32.4° to 1.14° (Wide-Tele) Diagonal field of view: 63° to 2.34° (Wide-Tele)
|
| Minimum Working Distance: |
10-1,500mm(Wide-Tele)
|
| Aperture Range: |
F1.2 to F4.4
|
| Pan Range: |
360°endless
|
| Pan Speed: |
Pan Manual Speed: 0.1°-160°/s, Pan Preset Speed: 240°/s
|
| Tilt Range: |
-15°-90° (Auto Flip )
|
| Tilt Speed: |
Tilt Manual Speed: 0.1°-120°/s, Tilt Preset Speed: 200°/s
|
| Proportional Zoom: |
Rotation speed can be adjusted automatically according to zoom multiples
|
| Number of Preset: |
300
|
| Patrol: |
8 patrols, up to 32 presets per patrol
|
| Pattern: |
4 pattern scans, record time over 10 minutes for each scan
|
| Power-off Memory: |
Support
|
| Park Action: |
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
|
| PTZ Position Display: |
ON/OFF
|
| Smart-tracking: |
Support
|
| IR Distance: |
150m
|
| IR irradiation angle: |
Adjustable by zoom
|
| Alarm Input: |
2
|
| Audio Input: |
1-ch audio input
|
| Audio Output: |
1-ch audio output
|
| Ethernet: |
10Base -T, /100Base-TX, RJ45 Connector
|
| Max.Image Resolution: |
1920×1080
|
| Main Stream: |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720), 50fps (1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720), 60fps (1920 × 1080, 1280 × 960, 1280 × 720)
|
| Sub Stream: |
50Hz: 25fps(704×576, 640×480,352×288); 60Hz: 30fps(704×480, 640×480,352×240)
|
| Third Stream: |
50Hz: 25fps(1920×1080, 1280×960, 1280×720, 704×576, 640×480,352×288) 60Hz: 30fps(1920×1080, 1280×960, 1280×720, 704×576, 640×480,352×288)
|
| Video Compression: |
Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264/MJPEG Third Stream: H.265/H.264/MJPEG
|
| ROI encoding: |
Support 4 areas with adjustable levels
|
| Audio Compression: |
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
|
| Audio Mode: |
OFF/Audio input/Audio output
|
| Protocols: |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
|
| Simultaneous Live View: |
Up to 20 channels
|
| Three-Stream: |
Support
|
| Storage: |
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB
|
| User/Host: |
Up to 32 users, 3 levels: Administrator, Operator and User
|
| Security Measures: |
User authentication (ID and PW), host authentication (MAC address)
|
| Client: |
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
|
| Web Browser: |
IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51
|
| Language |
English
|
| Power Supply: |
24 VAC & Hi-PoE
|
| Power Consumption: |
Max.: 40 W (Max. 14 W for IR)
|
| Working Temperature/Humidity: |
-30 ℃-65℃(-22℉-149℉)(outdoor) 90% or less
|
| Protection Level: |
IP66 standard (outdoor dome) TVS 4,000V lightning protection, surge protection and voltage transient protection
|
| Mounting: |
Various mounting modes optional
|
| Material: |
ADC 12, PC, PC+10%GF
|
| Dimensions: |
Φ220×353.4mm (Φ8.66”×13.91”)(Outdoor)
|
| Weight (approx.): |
4.5kg(9.92Ibs)
|
